Portable Data Acquisition Systems

Users can configure the new DAS 1400 series portable paperless recorders to have from 6 to 36 analogue signal channels.This means one recorder can be used for different development, production or service data acquisition applications.

Up to three input modules can be installed. Two types are available: ‘Universal’ modules have 6 isolated channels for DC voltage (1mV to 1000V), true RMS AC (200mV to 500V) or thermocouple inputs. 12-input ‘multiplexed’ modules accept input signals up to 50V, thermocouple or PT100 sensors.

The DAS 1400 series offer direct recording onto the internal hard disk, with a bandwidth of up to 100kHz per channel. A 12-inch colour screen displays waveforms during acquisition, or from memory. Ethernet, USB and RS-232 interfaces are provided for data transfer to a network, external storage device or a PC for archiving and further analysis.

Panel Printers with USB or Profibus

Ideal for printing measured data, status and fault reports in instrumentation, automation and industrial process applications.

The IPP 140-40 GE series feature...

• Fast text, graphics or barcode printing
• A real-time clock can add date and time automatically
• Choice of USB, Profibus, RS232C or RS485 interfaces
• Memory to store texts. Variable data can be inserted
• Compatible with Windows(R) printer drivers

All models feature fast printing on 80mm wide 'document grade' thermal paper. Compact 144 x 72mm DIN size metal case. AC or DC power supplies. Paper re-roll unit and protective cover accessories. Key models available from RS Components

Multifunction Meters with Data Outputs

Save costs in project planning, system construction and stock holding. One multifunction power meter replaces numerous meters and transducers in electrical control, generator and building management systems

• Profibus-DP, RS-232 and pulse data outputs – link to PLCs, PCs or SCADA
• Measure Volts, Amps, Hz, Watts, kVA, kVAr, cosΦ, kWh . . .
• Maximum demand, 8 or 15min bimetal ammeter functions
• Record Min, Max. Average and Sum values
• Input voltages up to 690V can be directly connected
• User configurable for CT (1A or 5A) and VT ratios
• Single or three-phase systems
• Compact 96 x 96mm housing, just 58mm deep
• Competitive and convenient alternatives to traditional meters

Compact Process and Temperature Data Recorders

The new SRD-99 series are compact 96x96mm panel mounting data recorders designed to record and display process signals in numeric, tabular or graphical format. They are available in a choice of 1, 4 or 8-channel versions; with either temperature (Pt100/500/1000), or 0/4 to 20mA process control loop inputs. Each input can be simply named, scaled and captioned by the installer – using the front key operated menu.

Data recording can be automatic, or externally controlled by a data input, with programmable sample intervals from one second up to one hour. The internal memory is up to 8MB – enough to store 2 million data points.

All versions feature a built-in RS-485 (Modbus RTU) serial port for configuration using the supplied SRD Toolkit Windows® software, and data transfer to the Loggy Soft data analysis and archiving software. With the USB Host port option, data can be downloaded and transferred by a USB flash memory stick.

The STD-99 lockable clear plastic hinged front door accessory provides protection to IP 42 standards.

Thermal Recorders - 6 to 36 Channels

Users can configure the new 8440 series recorders to have from 6 to 36 analogue signal channels. This means one recorder can be used for different development, production or service applications. Up to three input modules can be installed. Two types are available: ‘Universal’ modules have 6 isolated channels for DC voltage (1mV to 1000V), true RMS AC (200mV to 500V) or thermocouple inputs. 12-input ‘multiplexed’ modules accept input signals up to 50V, thermocouple or PT100 sensors. The 8440 series offer direct recording onto the internal hard disk, with a bandwidth of up to 100kHz per channel. A 12-inch colour screen displays waveforms during acquisition, or from memory. The thermal printer outputs data in graphical or tabular formats. Ethernet, USB and RS-232 interfaces are provided for data transfer to a network, external storage device or a PC for archiving and further analysis. .

Arbitrary Generators - Making Waves

A new series of arbitrary function generators is available from Metrix Electronics.They can generate standard or user-defined waveforms with crystal-controlled sampling rates upto 125MHz , a 14-bit vertical resolution and up to 4 million horizontal points. Uses include signal simulation and test in many industrial, laboratory and service applications. Customised waveforms can be created from scratch, or by editing standard waveforms. A PC Arbitrary waveform editor program allows the user to create, edit and download complex waveforms, while multiple waveforms can be stored in flash memory. Three models offer standard 31, 40 or 50MHz; sine, square, ramp or pulse waveforms outputs. A fourth model has dual channel 50MHz outputs to operate independently or in sum mode to create more complex waveforms.

Numeric Displays for Field Bus

Comprehensive range of Mipan industrial displays for use with Field Bus, serial or analogue process control systems . . .

Dinalog Bargraphs

High-performance, robust alternatives to traditional electro-mechanical pointer instruments for displaying process variables such as level, flow, speed, rate & temperature - covering
simple trend indication up to sophisticated programmable analogue/digital controller applications.

• Single- and dual-channel versions
• Choice of DIN-sizes up to 144 x 36mm front bezel
• Vertical or Horizontal formats
• Sophisticated models have user-programmable features (scale range, digital read-outs & adjustable alarm limits)
• 4 versions available ex-stock from RS Components

Suitable for most industrial and process control applications including: instrument panels, mimic displays or control desk requirements.
