Overview
The Type MA-G.1 / Type MV-1.1s Measuring transducers from GMW – for easy installation with compact form-factor.
This new series replaces the renowned MU/MP transducers range, now discontinued – click here
MA-G.1 / MV-1.1s Features
- Easy installation with no programming needed
- Accuracy class of 0.5
- continuous Analog measurement
- Fail-safe analog output
- Front adjustment of zero and span
- dual output
- A Calibrated output double front with a switch that is switchable between 0 – 20 mA / 0 – 10 V and 4 – 20 mA / 2 – 10 V . With these Converters : direct current dimensions, root-mean-square value, process dimensions and arithmetic dimensions.
- Can be combined with frequency output and relay module
- 4 kV test voltage , even in DC auxiliary voltage between input, output and auxiliary power
all converters with auxiliary voltage for 36 – 265 V of AC + DC or 6 – 30 V of AC + DC and 4 kV of test voltage. - Narrow construction 22.5-mm case width
Please note, the transducers are now red colour cases (not green as shown here and in the catalogue) – updated images coming shortly. Product delivered will be red.
Type names and ordering numbers
MA-1.1s 7470100000 (MA1.1s)
MV-1.1s 7470200000 (MV1.1s)
MA-1.1s (eff) 7470300000 (MA1.1seff)
MV-1.1s (eff) 7470400000 (MV1.1seff)
MF-Fs 7470500000 (MFFs)
MPlz.1 7470600000
MW-1.1 7470700000 (MW1.1)
MWg-4.1 7470800000 (MWG4.1)
MWg-3.1 7470900000 (MWG3.1)
MWu-3.1 7471000000 (MWU3.1)
MWu-4.1 7471100000 (MWU4.1)
MB-1.1 7471200000 (MB1.1)
MBg-4.1 7471300000 (MBG4.1)
MBg-3.1 7471400000 (MBG3.1)
MBu-3.1 7471500000 (MBU3.1)
MBu-4.1 7471600000 (MBU4.1)
MPt.1 7471700000
MTh.1 7471800000
MWi.1 7471900000
MA-1.1s dir. 7472000000 (MA1.1sdir)
Multi-E4-MU 7473000000 (MultiE4MU)
Multi-E11-MU 7473100000 (MultiE11MU)
Multi-E-MU 7473200000 (MultiEMU)
MW-G.1 7474000000 (MWG.1)
MA-G.1 7474200000 (MAG.1)
MV-G.1 7474300000 (MVG.1)
MT-G.1 7474400000 (MTG.1)
MV-GT.1
MA-GT.1
